Certificatios

Performance through quality in a safe and healthy environment, documented by DNV certification for welding piping and general steel structures manufacturing.

Mgmt-SysCert-ISO9001-ISO-14001-ISO45001-col

Implemented the Integrated Management System for Quality, documented since May 2016 in accordance with requirements of:

Welding Inspector Certification:

CostescuEWE

TOP


MP CATEGORY	Manpower
WHITE collar	16 employees
PROJECT MANAGER	4 employees
FOREMAN	10 employees
PIPE FITTERS	70 employees
PIPE WELDERS	70 employees
PLATE WELDERS	20 employees
BENDING	10 employees
MECHANICAL	5 employees
CRANES OPERATORS	5 employees
ELECTRICIANS	5 employees
FORK LIFT OPERATORS	10 employees
UNSKILLED WORKERS	10 employees
TOTAL	235 employees


Activity/ Layout Code	Facilities	Concept / Remarks
Steel Stock	Capacity (Area, Bays5,6,7&8): Cranes:	~2,000 ton (~1,500 m2, 4 ) 2 x 3.2 ton (Bays 5&6)
Bending Pipes & Profile	Equipments:	−DN 40 ~133 −DN 15 ~ 45	Hydraulic Bending Electro-Mechanic Bending Facilities based on European&JIS&DIN Standards
T-Bar Fabrication	Area: T-Bar Line:	1,000 m2 −Edge preparation −Semi-Automatic Weld	The facility has one Oxy-Gas cutting machines.
Pipe Fabrication	Bays: Pipe Rotators:	2 bays: bay no 1& no 2 5	Facilities based on European&JIS&DIN Standards TIG 400, Semi-auto Arc CO2
Steel Outfitting Fabrication	Bays:	Totally 3 bays used for fabrication Separate shops inside Combined scissors FP-14 for profiles	cutting to the desired length of the semi rolled as: plates, profiles (U, L, T; I; .round, square, hexagon) Semi-auto Arc CO2
Minor Assembly	Cutting & Assembly Components & Sub-Ass’y of Tank’s Metallic Fabrication	Bay no 4
Transportation	Fork Elevator: Truck:	1 x 3.5 ton 1 x 5 ton 1 x 8.5 ton
Outdoor fabrication area	Lifting capacity	1 x 50T crane 2 x 16T cranes 1 x 50T auto-crane 1x 12T auto-crane

S.C UNION SERV S.R.L is a turnkey contractor – as manufacturer and assembler for on/offshore and shipbuilding piping projects as well as oil & gas, pharma and alimentary industries related installations and structures. Our fabrication facility is structured and organized for accommodating our work scope that includes all types of pipes (½ inch to 40 inch), steel plate and carbon steel as well as stainless steel materials such as pipe fittings, in all sizes and all types: plate, welded or seamless pipe products, for every shape and configuration, flanges and fittings.


Bays no	Bay category	Length	Width	Depth	Cranes
1	Carbon Steel pipe manufacturing	56 m	20 m	6 m	J1 x 5T
2	Carbon Steel pipe manufacturing	56 m	18 m	6 m	J1 x 3.2T
3	Carbon Steel pipe manufacturing	56 m	18 m	6 m	J1 x 3.2T
4	Stainless steel pipe manufacturing	56 m	18 m	6 m	J1 x 3.2T
5	Soft steel manufacturing	35 m	20 m	7.5 m	J1 x 3.2T
6	Soft steel manufacturing	15 m	20 m	7.5 m	J1 x 3.2T
7	Treatment	20 m	20 m	9 m
8	Indoor Storage&palletizing	10 m	20 m	9 m
